AP4121
50V，Step-down High Brightness
LED Controller
GENERAL DEscriptION
The AP4121 is a high efficiency step-down controller.It is designed to operate in continuous conduction mode and drive single or multiple series connected LED efficiently from a voltage source higher than the total LED chain voltage. It operates with a wide input voltage from 6V to 50V and provides an externally adjustable output current.
大功率升壓恒流芯片降壓IC恒流降壓IC驅動IC線性IC聯系歐陽：18811874036 QQ:2355558464
The AP4121 includes a high-side output current sense circuit, which uses an external resistor to set the nominal average output current, and a dedicated DIM input accepts either a DC voltage or PWM dimming.
The AP4121 is available in SOT23-6 packages.
FEATURES
l Simple low parts count
l Wide input voltage range: 6V to 50V
l High efficiency (up to 97%)
l Single pin on/off and brightness control using DC Voltage or PWM
l Up to 1MHz switching frequency
l Adjustable Constant LED Current
l Typical 3% output current accuracy
l High-Side Current Sense
l Hysteretic Control: No need compensation
l Inherent RCS open protection
l Inherent open-circuit LED protection
l Inherent short-circuit LED protection
l Thermal shutdown大功率升壓恒流芯片降壓IC恒流降壓IC驅動IC線性IC聯系歐陽：18811874036 QQ:2355558464
APPLICATIONS
l Low voltage halogen replacement LEDs l Automotive/Decorative lighting
l Low voltage industrial lighting l LED back-up lighting
l Signs/Emergency lighting
